Digital Signage Player

SI-344

AMD Ryzen™ Embedded 8000 series Processor Signage Player with AMD RDNA3 GPU and 4x HDMI

  • AMD Ryzen™ Embedded 8000 series Processors
  • Radeon RDNA 3 Radeon Graphics and XDNA Neural Processing Unit
  • 4x HDMI 2.1 with independent audio output support
  • iSMART intelligent energy-saving & Observer remote monitoring technologies
  • Built-in CEC and hardware EDID emulation functions with the software setting mode
  • 2x DDR5-5600 SO-DIMM, dual channel, Max. 256GB (with ECC)
  • 1x M.2 B-Key for 5G or LTE options
  • 1x M.2 E-Key for Wi-Fi, Bluetooth or capture card options
  • 1x M.2 M-Key for storage
  • Supports TPM 2.0 and watchdog timer
  • Slim and segregated flow ventilation design
  • NEW
  • Observer
System Mainboard MBD344
CPU AMD Ryzen™ Embedded 8000 Series Processors
CPU Socket FP7r2 BGA package
Chipset SoC integrated
Memory 2x DDR5-5600 SO-DIMM, dual channel, Max. 256GB (with ECC)
Graphics Radeon™ RDNA 3 Graphics
LAN 2x Gigabit LAN controller (One support OOB function)
Expansion Slots 1x M.2 E-Key (2230)
1x M.2 B-Key (3052)
1x SIM card slot
I/O Interface 4x HDMI 2.1 with hardware EDID emulation & CEC function
1x USB 3.2 @gen 2 (USB Type-A)
2x USB 2.0 (USB Type-A)
2x RJ45 for Gigabit LAN
1x RJ45 for RS-232 serial port
1x Audio connector for Line-out
1x Power button
1x Power jack (+12V DC)
2x Power/HDD LED
Auto Control and Monitoring Watchdog Timer: 256 segments, 0, 1, 2...255 (sec/min)
Power Requirement +12V DC-in
Construction Aluminum + SGCC
Weight TBD
Chassis Color Black & white
Storage 1x M.2 M-Key (2280)
Power Supply TBD
Mounting Slim design with wall mounting holes
Dimensions TBD
Operating Temperature 0°C~ 45°C (32°F~113°F)
Storage Temperature -20°C ~ 80°C (-4°F~176°F)
Relative Humidity 10%~90% (non-condensing)
Vibration M.2: 5 grms / 5~500Hz / random operation
Certification CE, FCC Class A, UKCA, cULus, CCC
Operating System Win11 IoT Enterprise(64-bit)
Linux Ubuntu(64-bit)
DATASHEETS SI-344
CATALOGS Digital Signage Players (Vol.25.05)
