Edge AI & Intelligent System
ES1002
Edge AI Server with AMD EPYC™ Embedded 8004 Series Processors
- AMD EPYC™ 8004 (Siena) Series Processors
- 6x DDR5 4800, up to 576GB, supports ECC
- 5x PCIe (x16) slots
- 2x USB 3.2 Gen1: 2x USB 3.2 Gen1 with PDPC support
- 4x SATA 6Gb/s
- 1x PCIe Gen5 22110/2280, 2x MCIO (x4)
- 2x Intel® X710-AT2 (Dual 10GbE port)
The ES1002 Edge AI Server is a high-performance platform engineered to accelerate next-generation edge AI and data-intensive applications. Powered by AMD EPYC™ Embedded 8004 (Siena) series processors, the system delivers up to 64 cores and 128 threads, enabling efficient real-time analytics, AI inference, and large-scale data processing at the edge.

With support for up to six DDR5-4800 RDIMM slots with a maximum capacity of 576GB ECC memory, along with five PCIe Gen5 x16 slots, the ES1002 provides exceptional computing power and scalability for demanding workloads. It features a 4U rackmount chassis design with a spacious internal layout that significantly improves thermal efficiency and overall system stability. This robust architecture is ideal for long-duration, high-load operations in mission-critical environments. In addition, multiple PCIe expansion slots enable flexible integration of network interface cards, GPUs, and a wide range of AI accelerator cards, allowing the system to adapt to diverse edge AI deployment requirements.
Designed to support a broad range of enterprise and edge scenarios, the ES1002 is ideal for enterprise application servers, data storage services, backup and data protection, as well as general network service nodes. Combining powerful computing performance, flexible expandability, high-speed connectivity, and a reliable design, the ES1002 serves as a robust and versatile infrastructure platform for organizations building scalable, future-ready edge AI and IT environments.
| System Mainboard | MBB1002 with AMD EYPC™ Siena 8004 Series CPU |
| CPU Type | AMD EYPC™ Siena 8000 Series CPU (225W cTDP) |
| System Speed | Up to 3.1GHz |
| Memory | 6x DDR5 4800, RDIMM 6 slots, Max. up to 576 GB Supports ECC 3600/4000/4400/ 4800 MHz,16 GB, 32 GB, 64 GB, 96GB |
| AI Inference Computing Power | AMD EPYC™ 8004 Series (Siena) processor with Zen 4c architecture / scalable performance up to 64 cores and 128 threads. / supports 5x Gen5 PCI-E (x16) |
| Front Panel External I/O | 3x LED (Power, HDD, Status) |
| Rear Panel External I/O | 2x USB 3.2 Gen1 with PDPC support 4x SATA 6Gb/s 1x PCI-E Gen5 22110/2280, 2x MCIO (x4) |
| Expansion Slot | 5x PCI-E (x16) slots - PCI-E (x16)_SLOT2 (Gen5 (x16) link, from CPU) - PCI-E (x16)_SLOT3 (Gen5 (x16) link, from CPU) - PCI-E (x16)_SLOT5 (Gen5 (x16) link, from CPU), CXL support - PCI-E (x16)_SLOT6 (Gen5 (x16) link, from CPU), CXL support - PCI-E (x16)_SLOT7 (Gen5 (x16) link, from CPU), CXL support |
| Storage | 4x SATA (6Gb/s) 1x NVME 22110/2280 (PCI-E Gen5) 2x NVME MCIO (x4) |
| Power Requirement | 1x 24-pin SSI power connector, 3x 8-pin SSI 12V power connector |
| Power Supply | 1x ATX standard 1200W PSU |
| Construction | Aluminum & steel |
| Chassis Color | Black |
| Mounting | N/A |
| Weight | TBD |
| Dimensions | 483 mm (W) x 510 mm (D) x 177 mm (H) 19" (W) x 20.1” (D) x 7" (H) |
| Operating Temperature | -10°C to 60°C (14°F~140°F) *with air flow -10°C to 50°C (14°F to 122°F) without air flow |
| Storage Temperature | -20°C to 80°C (-4°F to 176°F) |
| Relative Humidity | 0%~90% (non-condensing) |
| Vibration | Non-operating: 1.0 grms / 5~500Hz / random operation Operatiing:0.25 grms / 5~500Hz / random operation |
| Shock | Operating: 20 g / 11 ms Non-operating: 40 g / 11 ms |
| Certification | CE / LVD / FCC Class-B (TBD) |
| Operating System | Windows Server 2022 Windows Server 2025 Ubuntu 22.04 |
| ES1002 | Chassis with eATX motherboard w/o CPU, memory, storage, support AMD EYPC™ Siena 8004 Series processors |
| DATASHEETS | ES1002 |
| CATALOGS | Edge AI Products (Vol.25.12) |
| USER'S MANUALS | ES1002 V1.0 (IBASE Server) ES1002 V1.0 (Google Drive) |
