Network Appliance

INA2205

Entry 1U Network Appliance with Intel® Atom® Processor (formerly Amston Lake) & up to 8 GbE ports

  • Intel® Atom® x7405C Processor
  • 1x DDR5-4800 SO-DIMM, Max. 16GB (Non-ECC)
  • 4x 2.5G LAN RJ45 ports with 1 pair bypass on board and 2x 1G RJ45 LAN ports
  • 2x SFP ports
  • Supports open-frame 65W power supply
  • NEW
CPU Intel® Atom® x7405C Processor (6M Cache, up to 3.40 GHz) FCBGA1264
Chipset N/A
Memory 1x DDR5 SO-DIMM (Non-ECC)
Max. 16GB
Display 1x LCM
Ethernet 4x Intel® i226V RJ45 ports (support 2.5GbE)
2x Intel® i350-AM4 RJ45 ports (support 1GbE)
2x Intel® i350xAM4 SFP ports (support 1GbE)
Bypass 1x Segment, LAN5/LAN6
Expansion N/A
IPMI N/A
Storage 1x 2.5” HDD/SSD
1x M.2 SATA
TPM TPM 2.0
I/O 1x LCM
3x LED (Status/ HDD/ Power)
4x 2.5G RJ45 LAN ports
2x 1G RJ45 LAN ports
2x SFP
2x USB 3.0
1x Reset Button
Power Supply Open frame 65W power supply
Dimensions 438 (W) x 180 (D) x 43.5 (H) mm
Weight 6.5kg
Operating Temperature 0°C ~ 40°C
Storage Temperature -20° ~ 70°C
Operating Humidity 10 ~ 90%
Certification CE/FCC
INA2205 1U Rackmount Appliance, MBN2205 Intel® Atom® Processor SoC, 1x DDR5 SO-DIMM Max. 16GB, 4x 2.5GbE RJ45, 2x 1GbE RJ45, 2x GbE SFP, Open frame 65W PSU, CPU cooler, Barebone without RAM/HDD
DATASHEETS INA2205
CATALOGS Network Appliances (Vol.25.05)
DRIVERS - SYSTEMS INA2205 Driver DVD
