| Display Size | 19” TFT-LCD |
| Max. Resolution | 1280 x 1024 |
| Luminance (cd/m2) | 350 |
| Contrast | 1000 : 1 |
| Max. Color | 16.7M |
| View Angle (H/V) | 170/160 |
| Backlight Lifetime(hrs) | 50,000 |
| Touch Type | Resistive |
| Touch Interface | USB |
| Light Transmission (%) | 80 |
| Point of touch | 1 |
| USB 3.0/ 3.1 | Optional (M12) |
| USB 2.0 | 1 (M12) |
| RS-232/422/485 Selectable in BIOS | 1 (M12) |
| RS-232 | 1 (M12) |
| LAN | 1x GbE (M12) Second LAN (option) |
| Additional Graphics | None |
| Audio | None |
| Digital I/O | None |
| Power Connector | M12 connector |
| Power Button | None |
| Dimensions (mm) | 470 x 390 x 62.5 |
| Net Weight (kgs) | 17 |
| Processor | Intel® Atom® Processor E3845 1.91GHz |
| Memory | 2x DDR3L SO-DIMM, up to 8GB, default 4GB |
| Thermal Design | Fanless |
| Membrane Control | None |
| Built-in Speaker/MIC | None |
| Internal Expansion Bus | 1x Mini PCI-E(x1) [full/half-size] 1x Mini PCI-E(x1) [half-size] |
| Expansion Slot | None |
| Wireless | None |
| HDD | 1x 2.5” SATA |
| Removable | None |
| Power Input Range | 10V~30V DC |
| Chassis Material | 304 stainless steel / 316 stainless steel (option) |
| Color (Front/Back) | Silver / Silver |
| IP Rating | IP65 / IP69K |
| Mounting | VESA 75x75mm and 100x100mm |
| Operating Temperature | 0°C ~ 50°C |
| Storage Temperature | -20°C ~ 60°C |
| Storage Humidity | 10%~90% (non-condensing) |
| Certification | CE/FCC Class-B and LVD |
| Supported Operating Systems | Windows 10/ Windows 8 32-bit/64-bit, Windows 7 Pro for Embedded 64-bit, WES7 64-bit |
| INOSP-192-RE | 19” Stainless Steel Panel PC with IB897-I45P, Intel® Atom® Processor E3845 1.91GHz, 4GB DDR3L SO-DIMM, 64G SSD, resistive touch |
| DATASHEETS | INOSP-152-RE / INOSP-192-RE |
| CATALOGS | Panel PC (Vol.25.01) |
| USER'S MANUALS | INOSP_152-RE/INOSP-192-RE V1.0 |
| DRIVERS - SYSTEMS | INOSP-192-RE Driver DVD |
