RISC Platform

IPR-P07F-N

Industrial HMI with TI ARM® Cortex™ A8, Sitara™ AM3352 (1GHz) Processor

  • ARM Cortex A8 (1GHz)
  • 800x480 (WVGA) TFT, 300 cd/m², 20,000 hours
  • DC 24V+20%
  • Plastic chassis, fan-less design
  • Panel or VESA 75mm x 75mm mount, IP65 front bezel
  • ESD Protection : Level 4 (Contact Discharge 8KV,
  • Air-Gap Discharge 15KV), Class A
  • Suitable for industrial applications
Display type 7" TFT
Resolution 800 x 480
Display area 154.08mm x 85.92mm
Color depth 64K
Backlight type LED
Brightness 300 cd/m²
Backlight lifetime 20,000 hours
Viewing angle (H°/V°) 140/120
Contrast 500:1
Touch panel 4-wire resistive type
CPU ARM Cortex-A8 (1GHz)
Flash memory 4G Bytes eMMC
DRAM 512M Bytes
FRAM (non-volatile) 32K Bytes
RTC Yes
COM1 RS232/422/485
COM2 RS232/422/485
COM3 RS232/485 or CAN bus (option)
Ethernet 1x 10/100 Mbit or 2x 10/100 Mbit (option)
USB 1x Host, 1x Device
Memory card SD Card
Power supply voltag DC 24V ±20%, isolated power
Power consumption 8W
Operation temperature 0 ~ 50°C
Storage temperature -20 ~ 60°C
Humidity 10% ~ 90% (non-condensing) @40°C
Waterproof (front) IP65
ESD Protection Level 4 (Contact Discharge 8KV, Air-Gap Discharge 15KV), Class A
Dimension 199.8mm(W) x 147.8mm(H) x 39.8mm(D)
Cut-out 185.2mm(W) x 133.2mm(H)
Weight(Net) 0.68Kg
IPR-P07F-N 7”, 800x480 pixel, TI ARM ® Cortex ™ A8, Sitara ™ AM3352 (1GHz), eMMC 4G, SDRAM 512M, COM1 (RS232/RS422/RS485), COM2 (RS232/RS422/RS485), COM3 (RS232/RS485), USB (1 Host/1 Device), Ethernet, SD Card, 24V ± 20% DC
DATASHEETS IPR-P07F-N
